Surface Mount Awning & Soffit Fixture
The LSI Surface Mount Awning and Soffit Fixture (SFS) transforms walk-up transition areas—guiding customers seamlessly from parking lot to store entrance—with bright, reliable, and visually comfortable illumination.
Built to perform in any environment, the IP66-rated SFS is completely sealed against dirt, dust, and water, ensuring long-lasting performance in even the harshest conditions. Available in three color temperatures and lumen packages ranging from 4,000 to 10,000 lumens, it delivers the right light for every application. Choose a clear lens for maximum output or a diffuse lens for exceptional visual comfort—tailoring the experience to your space while maintaining superior efficiency.
Ideal Applications: Retail store soffits and awnings, convenience store lighting, low mount height canopy applications
Who sells our products? Various lighting sales agents, lighting manufacturer’s representatives, lighting distributors. See our Sales Representative Locator.
Features & Specifications
Ultra-slim 15/16” profile die cast housing with powder coated finish.
Symmetric optics mounted behind a clear or diffuse flat tempered glass lens.
Standard color is white and is finished with LSI’s DuraGrip polyester powder coat process. DuraGrip withstands extreme weather changes
without cracking or peeling. It is also available in bronze or black finishes.
Operating temperature: -40°C to +50°C (-40°F to +122°F).
Meets Buy American Act requirements.
Resources & Downloads
Photometrics & Applications
Markets
- Allproducts
Refueling Canopy Design Selector
Use the Refueling Canopy Design Selector to find the appropriate LED lighting design(s) for your specific needs.
Lighting Calculation Tools
Typical Canopy: 86′ x 45′ x 15′
Reflectances: Canopy-50% Pavement-15% Walls-0% (To simulate no walls)
Target Value: 25fc Average
