Clarity Direct/Indirect Linear

CLRL

Continuous Linear lighting has gained in popularity over the past decade and is very often the go-to solution for many commercial new construction lighting designs. The Clarity-series Linear (CLRL) has a unique ability to transform any space to create a welcoming ambiance. Direct and indirect components of the light distribution produce a volumetric fill that results in lower glare compared to direct-only sources. CLRL does this without compromising on its class-leading efficacy or its state of the art performance. The CLRL makes single power feed continuous run installations a breeze using the built in quick connects on both ends of every luminaire.

CLRL is available in both fixed and field selectable configurations. CCT selection can be achieved with the flick of a switch between 3000-3500 and 4000K, while lumen output stays fixed at 1,200 lumens/ft. At over 10,000 lumens in an 8ft. configuration, the direct/indirect linear produces ample light for most applications without causing glare.

The Clarity Linear’s sturdy construction (4ft. and 8ft. lengths) is paired with integrated capability for easy continuous row mounting without snaking as well as single feed wiring. This reduces installation costs and imparts clean lines and clear light to any interior space. CLRL is available in matte white or black finish.

This differentiated linear lighting solution is a great fit for applications such as Class-A office, Education, Retail, Hospitality, Quick-Serve Restaurants and Automotive Dealerships. CLRL is DLC listed and is eligible for state and utility rebate programs where available.

Ask a Question

Features & Specifications

Max Lumens
10,400
Min Lumens
4,800
Life Safety Features
Remote Emergency Battery Backup
Sensors
AirLink Blue External Sensor
Color Temperatures
3500 4000
Additional Options
Battery BackupBluetoothDimmableDLCTitle 24 CompliantUL ListedUL Listed Damp LocationQuickShip Eligible

Resources & Downloads

Photometrics & Applications

CLRL BIMobject® REVIT® Family



Lighting Layout Request BIM (Revit) Library

Lighting Calculation Tools

Typical Room: 40′ x 40′ x 10′
Calculation Reflectances: Ceiling-80%  Walls-50%  Floor-20%
Target Value: 45fc Average

Product Videos

Clarity Linear Continuous Run
